Technical overview

Instrumentation Design &
PLC/DCS Engineering

Instrumentation and control engineering bridges process design and operational reality. Poorly selected field instruments, a DCS architecture that cannot handle the I/O count, or an HMI that overwhelms operators during upsets are common root contributors to process incidents. Arborion Global delivers vendor-neutral instrumentation and control system design — from field instrument datasheets through DCS architecture, HMI graphics, alarm rationalisation, and SIS integration — aligned to ISA, IEC, and NAMUR standards.

Instrumentation Design & PLC/DCS Engineering — Overview
Engineering process

Instrumentation Design & PLC/DCS Engineering workflow

Control & Safety Philosophy

Gather control philosophy, P&IDs, SRS, HFE requirements, and alarm philosophy as the design basis.

Field Instrument Selection

Select transmitter type, accuracy class, rangeability, process connection, and hazardous-area certification for each tag.

Control System Architecture

Define DCS/SIS/PLC topology, I/O count, network segregation, redundancy, and uninterruptible power supply.

HMI & Alarm Design

Develop HMI graphics per ISA-101; rationalise alarms per ISA-18.2; conduct human factors review.

Cause-and-Effect Logic

Develop C&E matrix linking all trip initiators to ESD/F&G outputs with voting, bypass, and inhibit logic.

FAT/SAT Specification & Support

Prepare test specifications covering all logic paths; witness factory and site acceptance tests; issue punch list.

Instrumentation Design & PLC/DCS Engineering — Scope
Scope of work

Every deliverable — from basis to handover

Complete Instrumentation Design & PLC/DCS Engineering scope — every calculation, drawing, specification, and construction support activity.

Field instrument selection: flow, level, pressure, temperature, and analyser for each service
Instrument index, datasheet, and tag register development
Control system architecture: DCS, safety PLC, F&G, and BPCS/SIS network segregation
HMI graphics design per ISA-101 Level 1–3 hierarchy with HFE review
Alarm rationalisation per ISA-18.2: set-point review, nuisance alarm elimination, priority matrix
Cause-and-effect matrix linking all trip initiators to ESD and process trip effects
SIS integration: sensor common-cause separation, SIS-DCS interface, and proof-test plan
Control room layout and operator workstation ergonomics review
Engineering outcomes

Outcomes of Instrumentation Design & PLC/DCS Engineering

Instrument Reliability & SIL Compatibility
  • Builds out SIS integration and DCS-SIS separation
  • Reduces operator error via better HMI
  • Supports SIL claim verification
  • Improves alarm management
IEC 61511 / ISA-5.1 Instrument Defence
  • Maps to ISA-5.1, ISA-18.2, ISA-101
  • Documents IEC 61511 SIS lifecycle
  • Supports NAMUR NE compliance
  • Customer-audit defensible
Loop Availability & Control Quality
  • Improves DCS tuning and response
  • Reinforces operator situation awareness
  • Reduces nuisance alarms
  • Backs realistic operator training
Instrumentation Lifecycle Efficiency
  • Right-sizes instrument and control system cost
  • Reduces commissioning rework
  • Improves vendor pricing through clarity
  • Supports lifecycle optimisation
