Functional Safety Lifecycle Implementation
We provide full IEC 61511 Ed.2 lifecycle assurance from hazard and risk assessment through to decommissioning
Functional Safety Lifecycle Implementation element by element
Each element below has its own dedicated implementation page with focused methodology, flow chart, and individual significance for organisations. Click any element to explore.
We run the initial hazard and risk assessment that identifies hazardous events and the required risk reduction to IEC 61511 1 clause 8
We allocate the required risk reduction across the basic process control system, alarms, the safety instrumented system and the non instrumented layers to IEC 61511 clause 9
We author a safety requirements specification compliant with IEC 61511 clause 10 that sets the functional and integrity requirements for each safety instrumented function
We handle architecture, FMEDA, probability of failure calculation and cybersecurity to IEC 61511 clauses 11 and 12
We run factory acceptance testing, site acceptance testing, loop testing and end to end validation to IEC 61511 clauses 13 through 15
We manage proof testing, repair, demand response and bypass control to IEC 61511 clause 16
We govern controlled change to the hardware, software and operating conditions of the safety instrumented system to IEC 61511 clause 17
We deliver safe removal from service with hazard mitigation to IEC 61511 clause 18
We provide independent verification at every lifecycle phase to IEC 61511 clause 7
We run the Stage 1 through Stage 5 functional safety assessment audits to IEC 61511 clause 5 for independent integrity assurance
We deliver programme governance, competence and documented procedures to IEC 61511 clauses 5 and 6
Functional Safety
Lifecycle Implementation
IEC 61511 Ed.2, issued in 2016 with Amendment 1 in 2017, defines 16 lifecycle phases organised under hazard and risk assessment, allocation, realisation, operation and modification. The 2016 revision tightened the management requirements significantly, calling for explicit competence at each phase, a functional safety assessment cadence across Stages 1 to 5, rigour in prior use justification for non certified devices, a security threat assessment that is now mandatory under clause 8.2.4, and safety manual content under clause 16. The most common audit findings stay stable across geographies and operators, namely under documented prior use claims, a bypassed Stage 3 pre startup assessment, gaps in assessing the MOC change impact on SIL, misrepresented proof test coverage, and clause 5 competency records that lack role specific evidence. When our team runs a robust functional safety management programme we treat the safety instrumented system as a lifecycle asset, we integrate upstream with HAZOP, LOPA and SIL allocation and downstream with proof test execution and impairment management, and we produce an audit pack ready for a TUV, exida or third party assessment at any phase boundary.
Functional Safety Lifecycle Implementation workflow
Develop Functional Safety Management Plan per IEC 61511 Cl.5, assign phase specific competence requirements, verify role credentials, and establish FSA Stage 1, 5 examination schedule.
Define H&RA, Allocation, SRS, Design, Installation, Validation, O&M, and Modification phase outputs, set gate criteria and documentation requirements at each phase boundary.
Complete hazard analysis and risk assessment, develop Safety Requirements Specification, allocate safety functions across SIS, BPCS, and non instrumented protection layers.
Review SIS architecture and SIL verification, develop Safety Manual per Cl.16, conduct FSA Stage 2 (pre installation) and Stage 3 (pre startup) with independent examination.
Establish proof test procedures with coverage analysis, develop bypass approval workflow and time limit governance, integrate with CMMS for work order and impairment tracking.
Implement SIS MOC change impact on SIL procedure, schedule periodic FSA Stage 4/5 examination, update lifecycle records per IEC 61511 Cl.16 and decommissioning per Cl.18.
Every deliverable from basis to handover
Complete Functional Safety Lifecycle Implementation scope covering every calculation, drawing, specification, and construction support activity.
Outcomes of Functional Safety Lifecycle Implementation
- We close the silent SIL degradation pathway that uncontrolled MOC drives
- We anchor competence to the role so you avoid the pattern of an unqualified engineer executing the work
- We surface lifecycle weaknesses at the functional safety assessment before they show up in incidents
- We embed cyber physical security as a mandatory dimension of the lifecycle
- We give you full IEC 61511 Ed.2 lifecycle defence under a TUV, exida or third party assessment
- We close the typical audit finding clusters around prior use, clause 5 competence and the MOC impact on SIL
- We satisfy OSHA PSM mechanical integrity for the system as safety critical
- We align the work with the Seveso III and COMAH operational control evidence
- We reduce your spurious trip exposure through proof test design that is aware of the mean time to spurious failure
- We tighten impairment management so you avoid the cumulative bypass pattern
- We build reusable safety manual content across your multi site or multi asset programmes
- We drive consistent asset management discipline for the system across your CMMS and enterprise asset management
- We reduce your vendor lock in to fully certified components through prior use justification
- We help you avoid the re engineering cost that late discovery of an incomplete specification or safety manual brings
- We help trim insurance loadings through documented assessment discipline
- We help you defer system rebuild capex by sustaining the as designed SIL through proper operation and maintenance
Codes & standards we work to
Triggers that signal the need
Where Functional Safety Lifecycle Implementation applies
Wellheads, separators, gas compression, FPSO topsides, produced water systems.
Distillation columns, reactors, heat exchangers, storage spheres, LPG handling.
Cryogenic exchangers, liquefaction trains, BOG compressors, storage and sendout.
Reactive systems, batch reactors, solvent handling, runaway reaction scenarios.
Boilers, HRSGs, steam headers, hydrogen systems, ammonia SCR units.
Sterile vessels, CIP/SIP, pressure fermenters, solvent recovery, spray dryers.
Tangible deliverables
- Functional safety management plan under clause 5 with role specific competence records
- Lifecycle phase activity matrix and gate criteria
- Functional safety assessment Stage 1 to 5 charter, schedule and finding tracker
- Cybersecurity threat assessment under clause 8.2.4
- Prior use justification dossier for each non certified device
- Safety manual under clause 16 with operating, proof test, MOC and impairment instructions
- System modification procedure covering the MOC impact on SIL
- Decommissioning and learning capture procedure
- Annual functional safety assessment audit protocol
